Holophane - MICRO Ceiling recessed

Photometry Filter

Lumen

Colour Temperature

Power

Distributions

12°

33°

44°

Asymmetrical

Lumen (lm)	Colour Temperature (K)	Distribution
465	3,000	12°
485	4,000	12°
435	3,000	33°
455	4,000	33°
445	3,000	44°
460	4,000	44°
130	3,000	Asymmetrical
135	4,000	Asymmetrical

Download all Photometry and BIM Data

Gallery

Key Features

Those features, together with the extreme ease of installation, allow MICRO to be used as a single light point or in series, either on floor or ceiling. By means of monochromatic or dynamic light, it can highlight even individual architectural elements such as columns and statues.

Applications

Internal

Residential

Public Spaces

Distribution

12°

33°

44°

Asymmetrical

Specification

Body made of die-cast EN 44100 aluminium alloy, corrosion resistant. Protection with anodizing treatment, epoxy powder base coating and polyester painting. Closing ring made of AISI 316L stainless steel. 8 mm thick extra-clear flat tempered glass. Product with no visible screws with snap-in system for connection to the recessed box. IP68 protection rating with Full Dry system preventing condensation inside the product. Installation in recessed box set in concrete, with a 20-30 cm gravel drain bed. Only an IP68 rated connection to power supply cable can guarantee the IP68 protection rating to the luminaire.

Copy specification to clipboard

Dimensions

MICRO Ceiling recessed

Product code: 900IS

A recessed fitting with reduced size, only 95 mm diameter. MICRO is pure light: from a significant light beam when switched on, to disappearing when turned off.

Lumen	130 - 485
Power consumption	5.9 - 6
Distributions	4
IK Rating	IK08
IP Rating	IP68
Colour range	3,000 - 4,000
